Nano IO Expansion Shield for Arduino NANO 328P

This is Nano IO Expansion Shield for Arduino NANO 328P. It breaks out all pins as Electronic brick 3pin interface and a nRF24L01 wireless interface. And it supports 7-12V external power supply.

This extension plate provides all IO leads to 328P for the Arduino Nano. Introduces the electronic building blocks for 3 pin/sensor interface. Provide the external power input terminals, can support external 7-12V input. With 24 l01 XBee socket and plug, expanded the Arduino Nano wireless capabilities.

Nano IO expansion board is Arduino Nano a line board. It leads to the so-called all pins with 3 pin interface as the electronic building blocks, Zigbee XBee series modules and nRF24L01 wireless interfaces. Support the power converter is 7 to 12V.

Pins:-

1. I/O Pin- 14 I/O Pin (servo type with GND, power and signal)
2. Analog Pin- 8 Pins with power output and GND
3. PWM Pin- 6 Pins
4. Expansion Pin- 5 I2C Expansion Pins

You can use this module with Arduino Nano and Xbee

Features :

1. All digital and analog pins breakout
2. XBee and nRF24L01+ module interface
3. External power supply current support
4. Compatible pin map for electronic brick

Package Includes :

1 x Nano IO Expansion Shield for Arduino NANO 328P
