TNY279PN IC - Power Integrations Off Line Switcher IC

The TNY279PN incorporates a 700 V power MOSFET, oscillator, high voltage switched current source, current limit (user selectable) and thermal shutdown circuitry. The IC family uses an ON/OFF control scheme and offers a design fl exible solution with a low system cost and extended power capability.

Features:-

• Simple ON/OFF control, no loop compensation needed

• Selectable current limit through BP/M capacitor value

• Higher current limit extends peak power or, in open  frame applications, maximum continuous power Lower current limit improves efficiency in enclosed     adapters/chargers

• Allows optimum TNY279PN choice by swapping devices with no other circuit redesign Tight I2f parameter tolerance reduces system cost

• Maximizes MOSFET and magnetic power delivery

• Minimizes max overload power, reducing cost of transformer, primary clamp & secondary components ON-time extension – extends low line regulation range/hold-up time to reduce input bulk capacitance

• Self-biased: no bias winding or bias components

• Frequency jittering reduces EMI filter costs

• Pin-out simplifies heat sinking to the PCB SOURCE pins are electrically quiet for low EMI

Specification:-

Symbol	Parameter	Min	Type	Max	Units
VBP	BYPASS Pin Voltage	5.6	5.85	6.15	V
VBPH	BYPASS Pin Voltage Hysteresis	0.80	0.95	1.2	V
VSHUNT	BP/M Pin Shunt Voltage	6	6.4	6.7	V
ICH1	BP/M Pin Charge Current	-9.7	-6.8	-3.9	m A

Related Document:-

TNY279PN IC Data Sheet
