PC817 Optocoupler

In Stock

Brand: Generic | SKU: 8472927

₹ 8.00

~~₹ 11.00~~

Save 27%

Tax Included and Shipping Rate Calculated at Checkout

Min Qty: 5

Check Delivery Availability:

Enter your pincode to check delivery options

Offer & Other Details

Payment Offer: 2% Instant Discount on UPI and bank Transfer Payments.
Partial COD: Pay 25% Advance now and Balance on Delivery (COD).
Sales Assistance: Contact us +91 8903831010 for personalized advice.

Description

PC817 Series contains an IRED optically coupled to a phototransistor. It is packaged in a 4pin DIP, available in wide-lead spacing option and SMT gullwing lead-form option. Input-output isolation voltage(rms) is 5.0kV. Collector-emitter voltage is 80V(*) and CTR is 50% to 600% at input current of 5mA.

Features:-

â€¢ 4pin DIP package

â€¢ Double transfer mold package (Ideal for Flow Soldering)

â€¢ High collector-emitter voltage (VCEO:80V(*))

â€¢ Current transfer ratio (CTR : MIN. 50% at IF=5 mA, VCE=5V)

â€¢ Several CTR ranks available

â€¢ High isolation voltage between input and output (Viso(rms) : 5.0 kV)

Application:-

â€¢ I/O isolation for MCUs (Micro Controller Units)

â€¢ Noise suppression in switching circuits

â€¢ Signal transmission between circuits of different potentials and impedances

Specification:-

Symbol	Parameter	Value	Unit
IF	Forward current	50	mA
PD	Power dissipation	70	mW
VR	Reverse Voltage	6	V
Tstg	Storage temperature range	âˆ’55 to +125	Â°C
TOPR	Operating Temperature	âˆ’30 to +100	Â°C
TSOL	Lead Solder Temperature	260 for 10 sec	Â°C
IFM	Peak forward current	1	A
VCEO	Collector-emitter breakdown voltage	80	V
VECO	Emitter-collector voltage	6	V
