Meanwell RQ65B SMPS (5V, 12V, -5V, -12V) 62.5W Quad Output Switching Power Supply

Name: Meanwell RQ65B SMPS (5V, 12V, -5V, -12V) 62.5W Quad Output Switching Power Supply
Brand: Generic
SKU: 4602028

Out of Stock

Brand: Generic | SKU: 4602028

₹ 2,291.00

~~₹ 2,841.00~~

Save 19%

Tax Included and Shipping Rate Calculated at Checkout

Min Qty: 1 Shipped by 2 to 3 Weeks

Check Delivery Availability:

Enter your pincode to check delivery options

Offer & Other Details

Payment Offer: 2% Instant Discount on UPI and bank Transfer Payments.
Partial COD: Pay 25% Advance now and Balance on Delivery (COD).
Sales Assistance: Contact us +91 8903831010 for personalized advice.

Description

RQ-65B series is a 65W quad-output enclosed type power supply with 38mm of low profile design. The AC input is 88~264VAC which could be directly supplied from the house supplied voltage. The output Voltages from SMPS will be +5V, +12V,-5V, -12V. The SMPS has high efficiency up to 75%, the design is of metallic mesh case which enhances the heat dissipation of RQ-65B that the whole series operates from -25°C through +70°C. RQ-65B has complete protection functions and 5G antivibration capability; it complies with international safety regulations such as UL62368-1, TUV BS EN/EN62368-1. RQ-65B series can be used for many purposes with the best performance from it.

Pinout

Feature

Applications
