CD4049 Hex Inverting Buffer/Converter IC DIP-16 Package

The CD4049 device are inverting hex buffers, and feature logic-level conversion using only one supply voltage (V _CC ). The input-signal high level (V _IH ) can exceed the V _CC supply voltage when these devices are used for logic-level conversions. These devices are intended for use as CMOS to DTL or TTL converters and can drive directly two DTL or TTL loads. (V _CC = 5 V, V _OL ≤ 0.4 V, and I _OL ≥ 3.3 mA.)

Features:-

• CD4049 Inverting
• High Sink Current for Driving 2 TTL Loads
• High-to-Low Level Logic Conversion
• 100% Tested for Quiescent Current at 20 V
• Maximum Input Current of 1 µA at 18 V Over Full Package Temperature Range; 100 nA at 18 V and 25°C
• 5-V, 10-V, and 15-V Parametric Ratings

Specifications:-

Related Document:-

CD4049 IC Datasheet
